Linked Electronics Co., Limited One Stop PCB solution Provider
6 Years
| Ask Lasest Price | |
| Brand Name : | Linked |
| Model Number : | LPCB1001 |
| Certification : | UL, ISO9001, TS16949 |
| Price : | Based on Gerber Files |
| Payment Terms : | T/T, Western Union, Paypal |
| Supply Ability : | 10000sqm per month |
| Delivery Time : | 5 working days |
Automotive PCB Printed Circuit Board, Rohs compliant TS16949 Certificate
Linked Electronics is a China based PCB manufacturer with full in house manufacturing capabilities.
We specialized in high-mix, prototype, low volume and quick turn PCBs.
Our Capability
| Item | Capability | Remark | ||
| Layer count | 2~30 layer | |||
| Lamination | FR-4,Aluminum Based,Copper based,High frequency plate,Heavy copper,BT,Rogers,PTFE ect | |||
| Thickness (THK) | 0.2mm≤THK≤6.0mm | |||
| Smallest hole (mm) | 0.15mm | |||
| Aspect Ratio | 13:1 | |||
| Max dimension | Single or 2-layer | 600 x 1000 mm | ||
| Multi-lyr | ≤6L | 600 x 900 mm | ||
| ≥8L | 500 x 600 mm | |||
| Gold THK | Hard Gold (u") | 50u" | ||
| Immersion Gold (u") | 4u" | |||
| Copper THK | Outer (oz) | 6oz | ||
| Inner (oz) | 6oz | |||
| Smallest trace width / space (mil) | 3/3 mil | |||
| Annual ring | Via hole | 3mil | ||
| Component hole | 6mil | |||
| Copper to edge spacing | 0.25mm | |||
| Min trace width / space (mil) | Base Copper (oz) | Min trace width / space (mil) | ||
| 0.5 | 3/3 | |||
| 1 | 4/4 | |||
| 2 | 5/5 | |||
| 3 | 7/7 | |||
| 5 | 9/9 | |||
Our Advantage
1. High Capability and good management
Linked Electronics can meet all your PCB and PCBA manufacturing needs from single-sided to complex multi-layered PCB’s and everything in between. Our stringent quality standards are imposed by our trained staff with traceability of PCB’s throughout the production process. Our Management Team has over 15+ years experience which ensures we get the job done right.
2.Fast Lead time
Linked Electronics have a consistent on–time shipping record and we are now shipping many of our orders early!
3. Quick Turn-around Service
Prototype of 2 Layer can be finished within the working day, and 4 layer in 48 hours at Linked Electronics.
4. Good Service
At Linked we are committed to giving you personal Customer EXCELLENCE not just Customer Service! When you call, we answer. When you email, we respond.
5. Free Sample
For first time customers can receive first prototype for free by some restrictions applies. You will not be anxious about the potential risk because of initial cooperation.
6. No MOV
Linked Electronics don’t have any minimum lot requirements, so you
never have to buy more than what you need.
|
|
