PCB Assembly Services 1.6mm FR4 4 Layer PCB SMT for Custom Bluetooth Speaker
Welcome to Linked Electronics( One stop PCB solution service provider)
Linked Electronics has been manufacturing a wide range of high quality PCBs since 1995. We can meet your requirement of PCB prototype, or a complex, high volume PCB production. We provide high quality services to the electronic industries globally.
PCB Assembly Service Capability
| Item | Lot Size | ||||
| Normal | Special | Remark | |||
| PCB(used for SMT)spec | (L*W) | Min | L≥50mm | L＜50mm | Includes the Process Edge |
| W≥50mm | |||||
| Max | L≤460mm | L ＞ 460mm | |||
| W≤400mm | W＞ 400mm | ||||
| (Thickness) | Min thickness | 0.5mm | T＜0.5mm | ||
| Max thickness | 4.5mm | T＞4.5mm | |||
| SMT components spec. | dimension | Min size | 201 | 1005 | / |
| (0.6mm*0.3mm) | (0.3mm*0.2mm) | ||||
| Max size | 200mm*125mm | 200mm*125mm＜SMD | / | ||
| component thickness | T≤6.5mm | 6.5mm＜T≤15mm | / | ||
| QFP,SOP,SOJ(multipins) | Min pin space | 0.4mm | 0.3mm≤Pitch＜0.4mm | / | |
| CSP,BGA | Min ball space | 0.5mm | 0.3mm≤Pitch＜0.5mm | / | |
| Item | Prototype Manufacturer | ||||
| Normal | Special | Remark | |||
| SMT PCB SPEC | (L*W) | Min size | L≥50mm | L＜50mm | Includes the Process Edge |
| W≥30mm | |||||
| Max size | L≤450mm | L:800-450mm | |||
| W≤350mm | W:400-350mm | ||||
| (Thickness) | Minimum thickness | 0.8mm | T＜0.8mm | ||
| Maximum Thickness | 2mm | T＞2mm | |||
| DIP PCB SPEC | (L*W) | Min Size | L≥50mm | L＜50mm | |
| W≥30mm | |||||
| Max Size | L≤500mm | L≥500mm | |||
| W≤300mm | W≥300mm | ||||
| (Thickness) | Minimum Thickness | 0.8mm | T＜0.8mm | ||
| Maximum Thickness | 2mm | T＞2mm | |||
Linked aims to build a strong customer satisfaction community. We always work to maintain good relations with our customers by manufacturing custom PCBs as per their requirements. At every given opportunity, we put our sincere efforts to fulfill all customer's requirements.
It is most profitable to choose Linked for your PCB requirements as we supply:
Our Service includes
1. PCB fabricaton, full in house capability
2. Components procument
3. PCB Assembly Service
Look forward to your RFQs and we are always pleased to hear from you!!
Why Choose Linked Electronics
1) We are the manufacturer/ factory;
2) All the material we use have the UL & RoHS identify;
3) All the components we use are the New & Original;
4) One-stop service can be provided from PCB design, 1-32 layers PCB manufacturing, components sourcing, PCB Assembly, to Fully Product Assembly.
|
|
