Linked Electronics Co., Limited One Stop PCB solution Provider
6 Years
| Ask Lasest Price | |
| Brand Name : | Linked Electronics |
| Model Number : | LPCB1128 |
| Certification : | UL, TS16949, ISO14001, ISO9001 |
| Price : | by negotiation |
| Payment Terms : | T/T, Western Union,Paypal |
| Supply Ability : | 10, 000sqm per month |
| Delivery Time : | 5 working days |
| MOQ : | 1PCS |
OEM Prototype PCB Assembly LED Display Controller FR4 Electronic Board SMT
Linked Electronics has rich experience in PCB frabrication andPCB assembly. Backed by our advanced techniques and experienced production staff, Linked makes sure that all the layers in the multilayer PCB are perfect insulated between each other and every conductor pattern functions well. Our R&D team makes sure that we can provide PCB products to our customers according to their design or requirements. All our products, including PCB, are passed the certification of SGS, TS, RoHS and UL.
Look forward to your RFQ and hope we can work together.
PCB Assembly Service Capability
| Item | Lot Size | ||||
| Normal | Special | Remark | |||
| PCB(used for SMT)spec | (L*W) | Min | L≥50mm | L＜50mm | Includes the Process Edge |
| W≥50mm | |||||
| Max | L≤460mm | L ＞ 460mm | |||
| W≤400mm | W＞ 400mm | ||||
| (Thickness) | Min thickness | 0.5mm | T＜0.5mm | ||
| Max thickness | 4.5mm | T＞4.5mm | |||
| SMT components spec. | dimension | Min size | 201 | 1005 | / |
| (0.6mm*0.3mm) | (0.3mm*0.2mm) | ||||
| Max size | 200mm*125mm | 200mm*125mm＜SMD | / | ||
| component thickness | T≤6.5mm | 6.5mm＜T≤15mm | / | ||
| QFP,SOP,SOJ(multipins) | Min pin space | 0.4mm | 0.3mm≤Pitch＜0.4mm | / | |
| CSP,BGA | Min ball space | 0.5mm | 0.3mm≤Pitch＜0.5mm | / | |
| Item | Prototype Manufacturer | ||||
| Normal | Special | Remark | |||
| SMT PCB SPEC | (L*W) | Min size | L≥50mm | L＜50mm | Includes the Process Edge |
| W≥30mm | |||||
| Max size | L≤450mm | L:800-450mm | |||
| W≤350mm | W:400-350mm | ||||
| (Thickness) | Minimum thickness | 0.8mm | T＜0.8mm | ||
| Maximum Thickness | 2mm | T＞2mm | |||
| DIP PCB SPEC | (L*W) | Min Size | L≥50mm | L＜50mm | |
| W≥30mm | |||||
| Max Size | L≤500mm | L≥500mm | |||
| W≤300mm | W≥300mm | ||||
| (Thickness) | Minimum Thickness | 0.8mm | T＜0.8mm | ||
| Maximum Thickness | 2mm | T＞2mm | |||
Lead Time
Product Detail
| Layers | 4 |
| Material | FR4 High TG |
| Board Thickness | 1.6mm |
| Copper Thickness | 1oz |
| Surface Treatment | HAL Rohs |
| Soldmask & Silkscreen | Green/White |
| Quality Standard | IPC Class 2, 100% E-testing |
| Certificates | TS16949, ISO9001, UL, RoHS |
|
|
