Electronic PCB Assembly OEM FR4 94V0 Circuit Board Assembly
Since 1998, Linked Electronics has been serving the electronics industry with printed circuit boards and assembly services across the China and globally. Our business is to manufacture boards from 1 to 32 layers, provide quick turn consigned and full turn-key assemblies.
Linked Electronics' values are reflected in everything we do - from our focus on customers to our commitment to community. Our values serve as a foundation for how we conduct business, how we serve customers and how we treat each other.
We provide trustworthy products and services. We serve others with expertise and enthusiasm. We live by a code of rock-solid ethics, honesty and decency.
Linked Electronics' culture, the heart of our work environment, is one that supports our values as well as our business goals. It's one of the primary reasons why people come to work for us.
Linked Electronics
You can obtain price quotes on our website, or contact sales@linked-elec.com
As part of our constant efforts toward improvement, we welcome your
feedback.
Linked Electronics is all about delivering your printed circuit
boards and assemblies on time, and providing excellent quality.
We appreciate your business, and look forward to serving you
Assembly Capability
| Item | Lot Size | ||||
| Normal | Special | Remark | |||
| PCB(used for SMT)spec | (L*W) | Min | L≥50mm | L＜50mm | Includes the Process Edge |
| W≥50mm | |||||
| Max | L≤460mm | L ＞ 460mm | |||
| W≤400mm | W＞ 400mm | ||||
| (Thickness) | Min thickness | 0.5mm | T＜0.5mm | ||
| Max thickness | 4.5mm | T＞4.5mm | |||
| SMT components spec. | dimension | Min size | 201 | 1005 | / |
| (0.6mm*0.3mm) | (0.3mm*0.2mm) | ||||
| Max size | 200mm*125mm | 200mm*125mm＜SMD | / | ||
| component thickness | T≤6.5mm | 6.5mm＜T≤15mm | / | ||
| QFP,SOP,SOJ(multipins) | Min pin space | 0.4mm | 0.3mm≤Pitch＜0.4mm | / | |
| CSP,BGA | Min ball space | 0.5mm | 0.3mm≤Pitch＜0.5mm | / | |
| Item | Prototype Manufacturer | ||||
| Normal | Special | Remark | |||
| SMT PCB SPEC | (L*W) | Min size | L≥50mm | L＜50mm | Includes the Process Edge |
| W≥30mm | |||||
| Max size | L≤450mm | L:800-450mm | |||
| W≤350mm | W:400-350mm | ||||
| (Thickness) | Minimum thickness | 0.8mm | T＜0.8mm | ||
| Maximum Thickness | 2mm | T＞2mm | |||
| DIP PCB SPEC | (L*W) | Min Size | L≥50mm | L＜50mm | |
| W≥30mm | |||||
| Max Size | L≤500mm | L≥500mm | |||
| W≤300mm | W≥300mm | ||||
| (Thickness) | Minimum Thickness | 0.8mm | T＜0.8mm | ||
| Maximum Thickness | 2mm | T＞2mm | |||
PCB Assembly Service Process Flow
Products Show
|
|
