| Brand Name : | Linked Electronics |
| Model Number : | LPCB1429 |
| Certification : | UL, TS16949, ISO14001, ISO9001 |
| Price : | by negotiation |
| Payment Terms : | T/T, Western Union,Paypal |
| Supply Ability : | 10, 000pcs per month |
| Delivery Time : | 4 weeks |
OEM Automotive Green Electronic Printed Circuits Heavy Copper FR4 PCB Reach Compliant
Linked Electronics Co., Limited is one of the well-established China PCB manufacturer with more than 20 years of experience in producing one-sided, double-sided, and more than 20 years of track record in making multilayer printed circuit boards.
We specialize in comprehensive jobs: PRODUCTION – ASSEMBLY, including final TESTING. All that within EXPRESS lead times. We have very good relationship with leading gloal suppliers of parts and equipment. At Linked, we use the best raw material for PCB manufacturing.
Printed circuit boards from our production have a wide application which most are used in research, aerospace, medical, telecommunications, mining, and transportation industries as well as a multitude of common consumer electronic devices.
PCB Product Detail--OEM Automotive Green Electronic Printed Circuits Heavy Copper FR4 PCB Reach Compliant
PCB Manufacturing Capabilties at Linked Electronics
| Layers | Mass production: 2~32 layers / Proto run: 64 layers |
| Max. Thickness | Mass production: 394mil (10mm) / Proto run: 17.5mm |
| Material | FR-4 (Standard FR4, Mid-Tg FR4,Hi-Tg FR4, Lead free assembly material) , Halogen-Free, Ceramic filled , Teflon, Polyimide, BT, PPO, PPE, Hybrid, Partial hybrid, etc. |
| Min. Width/Spacing | Inner layer: 3mil/3mil (HOZ), Outer layer: 4mil/4mil(1OZ) |
| Max. Copper Thickness | UL certificated: 6.0 OZ / Proto run: 20OZ |
| Min. Hole Size | Mechanical drill: 8mil(0.2mm) Laser drill: 3mil(0.075mm) |
| Max. Panel Size | 1150mm × 560mm |
| Aspect Ratio | 12:1 |
| Surface Finish | HASL,Immersion Gold, Immersion Tin, OSP, ENIG + OSP, Immersion Silver, ENEPIG, Gold Finger |
| Special Process | Buried Hole, Blind Hole, Embedded Resistance, Embedded Capacity, Hybrid, Partial hybrid, Partial high density, Back drilling, and Resistance control. |
PCB Services that Linked Electronic Provides
1.PCB production of a wide range of Electronic PRINTED CIRCUIT BOARDS even for HIGH-END APPLICATIONS
2.PCB PROTOTYPING – production quantity from one unit in – EXPRESS
TIMES
SMALL, MEDIUM, AND LARGE PCB PRODUCTION RUNS or arrangement of
production using special technologies.
3.PCB ASSEMBLY with components as well as final functionality testing.
4. LASER CUT STENCILS with various specifications.
5. QUALITY GUARANTEE – 100% TESTING AND INSPECTION before shipping– testing and parameter measuring of printed circuit boards produced, including assembled boards (cross sectional examination of boards with components), utilizing non-destructive methods (electrical measurements or X-ray inspections) as well as destructive methods for bare PCB Board (metallographic cross-sectioning, thermal stress testing, solderability testing, and so on).
|
|
